Airmar B285C-HW Thru-Hull With Raymarine 11-Pin Mix-N-Ma

Airmar B285C High Wide 1Kw CHIRP Bronze Thru Hull with Raymarine 11-Pin Mix-N-Match Cable

Model: B285C-HW-11R

Depth & temperature

Bronze housing

Exclusive Xducer ID(R) technology

Get more coverage under the boat with Airmar's wide beam Chirp product line. Offering a high frequency range of 150-250 kHz and a constant 25 deg Beamwidth, these transducers are truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using the single band, wide beam transducers will achieve twice the coverage under the boat compared to our current high frequency Chirp transducers

A unique property of the high frequency transducers is that the Beamwidth is a constant 25 deg angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's new wide beam format also creates crisper and larger return images on the display. We've got you covered.

Specifications
CHIRP Frequency

150-250kHz
Beam width	Constant 25 deg
Maximum depth	500 feet

What's in the Box:

B285C

High Speed Fairing Block

MMC-11R-HM

DataSheet
