Airmar B175C-12-H Thru Hull With 9-Pin Humminbird MM Cable

Airmar B175C High Frequency CHIRP Transducer with 12d Tilted Element and Humminbird 9-Pin M&M Chirp Cable - 1m

Model: B175-C-12-H-HB

High-CHIRPS from 130 kHz to 210 kHz, 15 deg to 9 deg beamwidth

80 kHz of total bandwidth from one transducer

Hull Type: Fiberglass or wood

Depth & fast-response water-temperature sensor

Bronze transducer housing

Boat Size: Up to 11 m (36 feet)

Rely on Airmar's new broadband transducers for your ultimate fishing mission. Whether you're a commercial fisherman, charter captain, or tournament angler, there's a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000 feet) with 5 to 10 times greater detail and resolution so precise it's possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 80 kHz of total bandwidth in just one installation, saving customers time and money.

Thjis transducer terminates with Airmars Mix and Max connector, you can cut it off to connect to a sounder that does not require a connector.

Specifications
Hull Deadrise

8 deg to 15 deg
Acoustic window	Urethane
Boat size	Up to 11 m (36 feet)
Hull type	Fiberglass or wood
Frequency	130-210 kHz

What's in the Box:

B175 High Frequency Transducer

Humminbird 9-Pin M&M Chirp Cable - 1m

DataSheet
