Raymarine GA200 GPS Antenna

Raymarine GA200 GPS AntennaFor AIS4000/5000

Model: A80589

10 m (33 ft.) fitted cable

Low power consumption

Surface or pole mountable

The GA200 is an external antenna, suitable for improving the reception of the internal GPS/GNSS receivers of compatible Raymarine chartplotters, AIS devices, and VHF radios.

Compatible Chartplotters and multifunction displays:Axiom Pro/Axiom 2 ProAxiom XLeS97/eS98/eS127/eS128a95/a97/a98/a125/a127/a128

Compatible AIS Receivers:AIS5000AIS4000AIS700AIS350/AIS650

Compatible VHF radios:Ray90/Ray91Ray63/Ray73Ray53

Specifications
Diameter

85 mm (3.35 in)
Height (including pole mount adaptor)	70 mm (2.76 in)
Height	34 mm (1.34 in)
Unboxed weight (including cable)	0.5 Kg (1.1 lbs)
ENVIRONMENTAL
Waterproof rating	IPx6, IPx7
Storage temperature range	-30 degC to +70 degC (-22 degF to +158 degF)
Operating temperature range	0 degC to +55 degC (+32 degF to +131 degF)
Relative humidity	0.95

What's in the Box:

GNSS antenna, with captive cable 10m (33 ft).

Antenna pole mount adaptor

Antenna gasket

Antenna fixings (3 x M3x40 stud and thumb nut)
