B&G Triton Edge Sailing Processor

B&G TritonTM Edge Sailing Processor with NMEA 2000(R), Ethernet and built-in Wi-Fi.

Model: 000-15134-001

Latest powerful micro processor provides all core instrument calculations

Enhanced feature set for serious cruising yachts

B&G App Integration

Integrated webserver provides easy access to system configuration and control

Record all you sailing data to the cloud

Review your sailing data using the B&G companion app

Backup, restore, and export of sailing data

Ethernet interface. Ethernet, 100Mbps, waterproof

Dual Wifi - Internet & Hotspot

NMEA 2000(R) compliant interface (Micro C)

LED status indicators

Simple mounting, connectivity and a low profile design allows discrete and ease installation on any yacht.

12/24V power

TritonTM EdgeTM Sailing Processor delivers an enhanced suite of sailing data such as advanced StartLine calculations, advance true wind data and autocalibration, boat speed calibration and correction, wind correction for heel/trim, improving accuracy of your sailing information. Wi-Fi and Ethernet allow for expanded integration with TritonTM 2 and Nemesis(R) displays, and VulcanTM and Zeus(R) Chartplotters, whilst integration with the B&G(R) App also enables the ability to review or replay your sailing data, and web-browser based control allows for easy set-up and commissioning.

Specifications
Operating temperature

Minus 15 to 55oC (5 to 131oF)
Storage temperature	Minus 40 to 85oC (Minus 40 to 185oF)
Waterproof rating	IPX6; IPX7
Electrical
Supply voltage	12/24V DC nominal (9-31V DC)
Physical
WeightWeight	260g (0.57lbs)
Compass Safe Distance	0.5m (1.6 feet)
Interface/Connectivity
NMEA 2000(R)	1x Micro-C
Ethernet	1x Navico 5 pin yellow
WiFi	802.11 b/g; Internal antenna

What's in the Box:

Triton Edge Processor

4-Pin Power Cable

N2K T-Joiner

N2K Cable - 0.6m (2ft)
