In-line 4 200 / 150 hp

or
Call +1 631-728-9200

Description

200 HP

With impressive power-to-weight, volumetric efficiency, and integrated steering, this In-Line Four is the perfect, lightweight 200-hp solution for small- to medium-size boats. Its unique Variable Camshaft Timing (VCT) improves intake and exhaust efficiency and boosts torque throughout the rev range.

  • Comes with integrated electro-hydraulic steering for digital models and integrated hydraulic steering for mechanical models
  • Runs on economical 89 octane
  • Only 525 pounds (20” shaft DEC model)
  • 20” or 25” shaft options
  • 50-amp alternator provides plenty of power for onboard electronics
  • Digital F200 available in signature Yamaha gray, pearlescent white, and classic white
  • Mechanical F200 available in signature Yamaha gray

    • Specifications

    ManufacturerYamaha
    ConditionNew
    Weight †Mechanical - 234 kg (516 lbs) / DEC - 238 kg (525 lb)
    Full Throttle RPM Range5000 ~ 6000 rpm
    Fuel Induction SystemEFI
    Recommended Engine OilYamalube® 4M (See owner's manual)
    Engine TypeInline 4
    Displacement2.8L
    Bore x Stroke96 x 96.2mm (3.78 x 3.79in)
    Prop Shaft Horsepower200hp @ 5500 rpm
    Alternator Output at W.O.T.50 Amp
    Compression Ratio10.3:1
    Recommended FuelOctane 89
    Recommended Fuel FiltrationYamaha 10 Micron Fuel/Water Separating Filter (external)
    C.A.R.B. Rating3-Star
    ExhaustThrough Propeller
    Intake16-valve
    IgnitionTCI Microcomputer
    Spark PlugNGK-LFR6A-11
    Starting SystemElectric
    LubricationWet Sump
    Engine Oil Capacity4.5L/4.3L w/without filter
    Recommended CoolingThermostatic Control
    Ethanol Blend Limit10% Maximum
    Gear Ratio1.86:1
    Gear ShiftForward, Neutral, Reverse
    Shaft Length20" / 25"
    Degree of Tilt70°
    Degree of Trim-4° through +16°
    Mounting Centers26"
    Steering Angle (maximum)30° from center, either direction
    WarrantyLimited 3 Year Limited Pleasure Boat - 1 Year Limited Commercial
