Jet Drive
Description
150 HP
Our 2.7-liter F150 Jet Drive outboard produces 105 hp at the pump. It features a DOHC, 16-valve design with four valves per cylinder and long tube intake tracks. This produces ample power for navigating shallow, rocky water.
Specifications
| Manufacturer | Yamaha |
| Condition | New |
| Weight † | 225kg (493 lbs) |
| Full Throttle RPM Range | 5000 ~ 6000 rpm |
| Fuel Induction System | EFI |
| Recommended Engine Oil | Yamalube® 4M (See owner's manual) |
| Engine Type | Inline 4 |
| Displacement | 2.7L |
| Bore x Stroke | 94mm x 96.2mm (3.70 x 3.79 in) |
| Prop Shaft Horsepower | 105hp @ 5500rpm |
| Alternator Output at W.O.T. | 35 Amp |
| Compression Ratio | 9.0:1 |
| Recommended Fuel | Octane 87 |
| Recommended Fuel Filtration | Yamaha 10-Micron Fuel/Water Separating Filter (external) |
| C.A.R.B. Rating | 3-Star |
| Exhaust | Through Jet Nozzle |
| Intake | 16 |
| Ignition | TCI Microcomputer |
| Spark Plug | LFR5A-11 |
| Starting System | Electric |
| Lubrication | Wet Sump |
| Engine Oil Capacity | 4.5L/4.3L |
| Recommended Cooling | Thermostatic Control |
| Ethanol Blend Limit | 10% Maximum |
| Gear Ratio | Direct Drive |
| Gear Shift | Forward, Neutral, Reverse |
| Shaft Length | Fits 25" Transom |
| Degree of Tilt | 70° |
| Degree of Trim | -4 through 16° |
| Mounting Centers | N/A |
| Steering Angle (maximum) | 35° from center, either direction |
| Warranty | Limited 3 Year Limited Pleasure Boat - 1 Year Limited Commercial |
