In-line 4 175 / 150 / 115 / 90 hp

or
Call +1 631-728-9200

Description

175 HP

Lean and mean, the In-Line Four V MAX SHO® 175 delivers exhilarating hole shot and class-leading top speed. It clocked in at 62 mph with a tournament load—up to five mph faster than its VF150 sibling.*

  • 2.8L high-output four cylinder
  • 480 lbs. dry weight
  • Shaft lengths available: 20” and 25”
  • 50 amps of charging power
  • New tilt stop lever
  • Optional Variable Trolling RPM via gauge

    • Specifications

    ManufacturerYamaha
    ConditionNew
    Weight †218 kg (480 lbs) - 222 kg (489 lbs)
    Full Throttle RPM Range5000 ~ 6000 rpm
    Fuel Induction SystemEFI
    Recommended Engine OilYamalube® 4M (See owner's manual)
    Engine TypeInline 4
    Displacement2.8L
    Bore x Stroke96 x 96.2mm (3.78 x 3.79in)
    Prop Shaft Horsepower175 hp at 5500 rpm
    Alternator Output at W.O.T.50 Amp
    Compression Ratio10.3:1
    Recommended FuelOctane 89
    Recommended Fuel FiltrationYamaha 10-Micron Fuel/Water Separating Filter (external)
    C.A.R.B. Rating3-Star
    ExhaustThrough Propeller
    Intake16
    IgnitionTCI Microcomputer
    Spark PlugLFR6A-11
    Starting SystemElectric
    LubricationWet Sump
    Engine Oil Capacity4.5L/4.3L w/without filter
    Recommended CoolingThermostatic Control
    Ethanol Blend Limit10% Maximum
    Gear Ratio1.86:1
    Gear ShiftForward, Neutral, Reverse
    Shaft Length20" - 25"
    Degree of Tilt70°
    Degree of Trim-4° through +16°
    Mounting CentersN/A
    SteeringMechanical Remote
    Steering Angle (maximum)32° from center, either direction
    WarrantyLimited 3-Year Pleasure, 3-Year Government, 1-Year Commercial
